The tablet making machine is used for pressing various raw materials into tablets,it's not only press round tablet, it can also press various shaped tablets, double lettering tablets, traditional chinese medicine tablets, western medicine tablets, calcium
tablets, buccal tablets, spirulina tablets, milk tablets, candy tablets, effervescent tablets, chewable tablets, flavoring blocks, chicken blocks, camphor tablets, aromatic tablets, disinfectant tablets, chemical fertilizer tablets, pesticide tablets, button batteries, electronic component, metallurgical powder, ceramic particles, etc.
ZP420-B series Alcohol block Effervescent cleaning tablet making machine:
1. There is a dedicated feeding system for equipment with poor liquidity materials.
2. The machine can be tested and adjusted without stopping the machine.
3. All controllers and operating components are arranged reasonably and easy to operate.
4. This device is a universal device with low maintenance costs and failure rates, and can be continuously produced 24 hours a day.
5. High pressure, smooth rotation, stable performance, safe and accurate, suitable for pressing various large and difficult to form tablets.
ZP420-B series Alcohol block Effervescent cleaning tablet making machine parameter:
| Model |
ZP-15B |
ZP-19B |
ZP-25B |
ZP-33B |
ZP-41B |
| Punch die No. |
15 |
19 |
25 |
33 |
41 |
| Max press diameter mm |
50 |
40 |
30 |
15 |
11 |
| Filling depth mm |
30 |
| Tablet thickness mm |
16 |
| Rotation speed r/min |
20 |
20 |
20 |
30 |
30 |
| Capacity pcs/hour |
36000 |
45600 |
60000 |
110000 |
140000 |
| Motor power kw |
5.5 |
5.5 |
5.5 |
4 |
4 |
| Size mm |
950*900*1550 |
| Weight kg |
1500 |
| Pressure KN |
120KN |
ZP420-B series Alcohol block Effervescent cleaning tablet making machine PHOTOS SHOW:
