Intelligent fully automatic bottle unscrambler machine for round shape plastic bottle
After pouring the bottles into the bottle compartment of the bottle sorting machine, the motor drives the bottle sorting tray to work through gear transmission. The bottles in the bin are rotated from the bottom of the sorting tray to the top of the sorting tray through the semi-circular groove of the tray.
The bottles in the semi-circular groove are sorted by the flipping plate of the sorting mechanism, automatically flipping the bottles with the mouth facing downwards and the bottom facing upwards, and neatly arranging them on the conveyor line for the next process.
Intelligent fully automatic bottle unscrambler machine for round shape plastic bottle features:
(1) The automatic bottle sorting machine is an automated equipment that integrates machine and electricity, and is controlled by Siemens PLC in Germany.
(2) Simple and easy to understand operation, stable and reliable equipment operation, simple and reasonable structure, and convenient maintenance and debugging.
(3) The equipment outlet is equipped with a photoelectric detection function, which mainly detects whether there is bottle blockage on the conveyor belt behind. If there is a bottle blockage, the equipment will automatically stop. If a shortage of bottles is detected, the equipment will automatically start up and send bottles.
(4) By utilizing an automatic bottle reversing mechanism and equipped with a bottle collection device, production efficiency is greatly improved.
(5) The body is made of high-quality 304 stainless steel material and has a fully sealed structure. Complies with GMP requirements.
Intelligent fully automatic bottle unscrambler machine for round shape plastic bottle parameter:
| Model |
BU-S |
| Suitable |
Bottle diameter 20-100mm, height 20-150mm |
| Speed |
30-150 bottle/min |
| Voltage |
220V/50HZ, 0.5KW |
| Wearhouse volume |
200L |
| Dimension |
1350*1000*1270mm |
| Weight |
230kg |
Intelligent fully automatic bottle unscrambler machine for round shape plastic bottle Electric Configuration:
| Name |
Brand |
| Control System (PLC) |
Siemens, Germany |
| Viewing bottle photoelectric |
Germany Sik |
| Air switch |
Delixi |
| Emergency stop switch |
Delixi |
| Switching power supply |
Delixi |
| Main motor |
Maili motor |
Intelligent fully automatic bottle unscrambler machine for round shape plastic bottle line:
